The Port Settings page of the web-based utility of the switch displays the current Green Ethernet and EEE modes per port, and allows the configuration of Green Ethernet settings on a port. This mode is only supported on RJ45 GE ports and does not apply to Combo ports. If the cable is shorter than 30 meters for Ten-Gigabit ports and 50 meters for other type of ports, the device uses less power to send frames over the cable, thus saving energy. After cable length is analyzed, the power usage is adjusted for various cable lengths.

Short Reach Mode - This feature provides power savings on a short length of cable.

This mode is supported on both Gigabit Ethernet (GE) and Fast Ethernet (FE) ports. Recovery from this mode to full operational mode is fast, transparent, and no frames are lost.

Energy Detect Mode - On an inactive link, the port moves into inactive mode and saves power while keeping the Administrative status of the port Up.

The Green Ethernet feature can reduce overall power usage in the following ways: Unlike Energy Efficient Ethernet (EEE), Green Ethernet energy-detection is enabled on all ports whereas only devices with gigabyte ports are enabled with EEE. Green Ethernet is a common name for a set of features that is designed to be environmentally friendly and reduce the power consumption of a device. Configure Green Ethernet Port Settings on a Switch Objective
